Nux Amp Academy Stomp

Amp-Modelling Pedal for Electric Guitar

• Physical modelling algorithm with separate preamp and power amp simulation
• Stereo CYBER IR engine with dual 1,024-sample resolution
• Independent preamplifier and power amplifier simulation with the TSAC-4K white-box amplifier modelling algorithm
• Amplifier modelling algorithm with full functionality (e.g. four inputs for patch cable jumps)
• Aluminium housing made of extruded aluminium
• Effect blocks NG, EFX, AMP, I.R, EQ, S/R, DLY and RVB with freely selectable and parallel routing sequence
• 2.86" colour LCD display (960 x 376) with intuitive operation
• 27 preset slots with three scenes and independent L/R 60 IR slots
• Pre/post-phrase looper for adjusting the sound from a distance (NBT-1 with app)
• Footswitch settings
• Global EQ
• Headphone level
• Aux input level
• Output level
• Quick block
• Tuner in global settings
• USB Audio Interface
• Firmware update and PC editing software
• Analogue / digital
• Presets: 27 x factory settings, 27 x user
• Number of EFX blocks: 9 (NG, CMP, EFX, AMP, EQ, S/R, IR, DLY, VB) Impulse Responses: Left & Right
• 60 x factory-set Cyber IRs
• 40 x user IRs USB: USB-C for 24-bit / 48kHz USB AUDIO
• USB MIDI (PC editor)
• Firmware update
• NBT-1 Bluetooth module with APP control
• Bluetooth: Additional NBT-1 module with APP control
• Expression control
• External EXP or additional NMP-2LITE footswitch
• Bypass switch: Buffered bypass
• Software: Amp Academy Stomp Editor (PC)
• Amp Academy Stomp APP
• Input/return pulse resistance: 1 MO
• AUX input impedance: 10 kO
• Output L/R impedance: 100 O (balanced)
• Send impedance: 1 kO
• Headphone output impedance: 10 O
• Dynamic range input to output L/R: 111 dB
• Sampling rate: 48 kHz / 32-bit
• System latency: at least 2 ms
• Power supply: 9 V DC (centre contact negative)
• Power consumption 500 mA
• Dimensions (L x B x H): 183 x 30 x 65.3 mm
• Weight: 0.9 kg
