Lake Lmx 48

Lake LMX 44, digital loudspeaker management system, 4x4 analog I/O with Iso-Float™, 4x4 AES3 digital I/O, 4x4 Dante/AES67 network I/O, 2x AES50 interfaces with up to 24 selectable channels from 96 AES50 channels, 16 input routers with four priorities for seamless failover, 16-channel module input mixer for Contour and MESA modules, 4x MESA, 2x Contour or 1x Contour/2x MESA module configuration, parametric EQ with raised cosine algorithms, Ideal Graphic EQ, crossover up to 48 dB/oct. , FIR filter, LimiterMax with peak and RMS limiter, delay up to 2 s, 24-bit AD/DA, 96 kHz internal, 32-bit floating point signal processing, propagation delay from 0.143 ms, Dante dual redundancy, AES67 multicast, GPI control, scene and frame presets, front IPS color display, 16x LED meter with mute buttons, control via Lake Controller or DLM, 4x XLR inputs, 4x XLR outputs, 2x XLR AES3 In/Out (4x4), 3x RJ45 for Dante/AES67/Control, 2x RJ45 AES50, 1x RJ45 GPI, 2x BNC Word Clock, dimensions (W x H x D): 483 x 88 x 404 mm (19" x 2U x 16"), weight: 6.6 kg
